Gear Cutting Machines
Maximum diameter of spur or worm wheel hobbed, mm 3150
Maximum module of gears hobbed, mm 12
Maximum face width of spur gear tooth, mm 400
Number of teeth cut 90-1000
Maximum hob diameter, mm 320
Maximum hob length, mm 400
Taper hole in hob spindle No. 6 Morse
Workpiece diameter 3150 mm x module 16
Gear hobbing machine for high precision gears 544M
Gear hobbing machine for high precision gears 546M
Maximum diameter of spur or worm wheel hobbed, mm 5000
Maximum module of gears hobbed, mm 16
Maximum face width of spur gear tooth, mm 400
Number of teeth cut 140-800
Maximum hob diameter, mm 320
Maximum hob length, mm 400
Taper hole in hob spindle No. 6 Morse
Workpiece diameter 5000 mm x module 16
Gear shaper machine 5M150P
Workpiece main diameter, mm 800
Face width, mm 160
Module of gears shapered, mm 1-12
Work table diameter, mm 800
Taper hole in spindle No. 5 Morse
Maximum cutter diameter, mm 200
Spindle (cutter) stroke, mm 200
Workpiece diameter 800 mm x module 12
Bevel gear generator 5A284
Wheel outside diameter, mm 1600
Module, mm 30
Number of teeth 10-150
Diameter of gear cutting heads, mm 450, 500, 630, 800, 1000
Face width, mm 250
Tooth spiral, mm 150-800
Spiral angle, deg 5-45
Whole depth, mm 60
Craddle moving, mm (max) 260
Diameter of tapered hole in workhead spindle, mm 200
Workpiece diameter 1600 mm x module 30
Workpiece main diameter, mm 500
Face width, mm 75
Module of gears shapered, mm 0,4-5
Weight of the machine, tn 4
Workpiece diameter 500 mm x module 5
Gear shaper machine LORENZ SNJ5
Gear grinder machine for spiral bevel 5A872
Maximum cone distance (0-degree spiral angle) 285 mm
Maximum cone distance (15-degree spiral angle) 350 mm
Maximum cone distance (30-degree spiral angle) 420 mm
Workpiece diameter 800 mm x module 16
Straight bevel gear generator 5C286P
Workpiece outside diameter if 10:1 ratio, mm 800
Module, mm 16
Whole depth, mm 35
Pitch apex to crown if pitch angle 30 degree, mm 400
Face width, mm 125
Pitch angle min-max 5 deg 42' - 84 deg 18'
Number of teeth 10-150
Workpiece diameter 800 mm x module 16
Straight bevel gear generator 5A250P
Workpiece outside diameter if 10:1 ratio, mm 500
Module, mm 10
Whole depth, mm 22
Pitch apex to crown if pitch angle 30 degree, mm 250
Face width, mm 90
Pitch angle min 5 deg
Number of teeth 10-200
Workpiece diameter 500 mm x module 10
